Compact Dual-Beam SIW Leaky Wave Antenna
Tech ID
P10-1306
Patent Status
Granted in India
Design Status
--
Technical Description
The present invention relates to a half-mode substrate integrated waveguide based leaky wave antenna designed for dual beam seamless scanning. This compact antenna features a first tapered feed section and a second tapered feed section, which facilitate efficient power distribution to two leaky wave antennas responsible for radiating distinct beams.
Problems Addressed
- High Cost
- Ground Plane Dependency
- Low Gain
- Tuning Challenges
- Bulky in Size
TARGET AUDIENCE
- RF and Antenna Engineers
- Telecommunications Industry
- Academic Researchers
- Defense and Aerospace Sectors
- Electronics Manufacturers
TECH FEATURES
- Compact in Size
- Reduction in Leakage Losses
- Power Recycle Structure and Folded Ground Plane
- Equal Gain in Both Beams
- Seamless Beam Scanning
P10-1306
Send download link to email.
Available For
Available for exclusive and non exclusive license
Sell off
Cost
—
Stage of Developments
Technology Validated
