Technical Description
The present invention relates to a multi-level inverters (MLI’s) which is directed towards a six switch five level switching capacitor-based single source double boost multilevel inverter (SSDB-MLI) featuring boost capability, lower component count and supports soft-start & quasi-resonant charging.
Problems Addressed
- Fails To Boost Voltage
- Expensive Configuration
- Short/Open Circuit Faults
- Lacks Soft-start, Quasi-resonant Charging
- Inefficient Double Voltage Boosting
Tech Features
- (SSDB-MLI) with Decreased Component Count Architecture
- 2x Boost of Input Voltage
- Five-level Voltage Output
- Six Different Switching Modes
- Reduced Current Stress Profile
Target Audience
- Solar Energy Integrators
- Industrial Equipment Manufacturers
- Power Electronics Producers
- Energy Storage Providers
- Electrical Grid Operators
Tech ID: P16-1318 TRL 5 Patent Status: Granted Available For Exclusive and Non-exclusive License
