Technical Description
This invention relates to an enhanced electrolyte circulation design for redox flow batteries utilizing pillar-supported electrode felts within the flow channel headers. The structural modification minimizes electrode intrusion into the flow channels, reducing pressure drops and optimizing reactant distribution for improved battery efficiency.
Problems Addressed
- High Ohmic Resistance
- Porous Electrode Intrusion
- Flow Channel Blockage
- Uneven Electrolyte Distribution
- Early Concentration Polarization
- Increased Pressure Drops
- Decreased Energy Efficiency
Tech Features
- Enhanced Electrolyte Circulation
- Reduced Pressure Drop
- Eliminated Felt Intrusion
- Enhanced Flow Distribution
- Improved Surface Area
- Efficient Pillar Supports
Target Audience
- Grid Energy Storage Sectors
- Redox Flow Battery Industries
- Electrochemical Cell Manufacturing Sectors
- Renewable Energy Integration Industries
- Advanced Electrode Fabrication Sectors
- Research & Development
Tech ID: P17-2024 TRL 6 Patent Status: Granted Available For Exclusive and Non-exclusive License
